Sun Bandit® SB 1200-B-PPK Off-Grid Solar Water Heater Inverter System (1-4 PV Panels)
NO BATTERIES. NO GRID CONNECTION.NO WORRIES.
Makes your off-the-shelf water heater tank operate with no grid
connection! Great for RVs, cabins, boats or even add an off-grid solar
preheat tank to your home's water heating system!
Featuring best-in-class technology and construction to provide years of clean, quiet, dependable hot water from the free energy from the sun.
Sun Bandit® is a
revolutionary new way in which solar is used to heat water. This
innovative new technology utilizes PV technology to deliver clean,
reliable hot water by putting the free energy of the sun to work for you
in ways that makes owning a solar system more practical and affordable
than ever before.
Achieving energy independence has never been easier than with a Sun Bandit® Solar Hybrid Energy System. Sun Bandit® patented
technologies eliminates the need for complex solar mechanical water
heating and replaces it with clean, simple to install and easy to
enjoy PV technology to effectively and efficiently provide hot water.
With advance micro grid technology and design, Sun Bandit® can deliver hot water even when the grid goes down. Sun Bandit® is the simplest solar hot water solution on the market, providing the most easy-to-use and economical way to go solar.
SB Off-The-Shelf Tank Conversion Kit
(Basic Kit, designed for 1 to 4 each 280 to 350 Watt PV Modules - tank, mounting and modules are not included)
One (1) Sun Bandit® AC Micro-Grid Inverter with whip (1 to 4 PV Modules 280W to 350W each)
One (1) Sun Bandit® System Monitor
SB1200-B AC Micro-Grid Inverter Technical Overview
technologies simplify installation, optimize performance and eliminate
the need for utility net-metering providing off-grid energy independence
even during a power outage.
• Complete autonomous operation with no grid-tie or batteries needed.
• 4 DC Input Channels with Maximum Power Point Tracking (MPPT) for each PV module.
• For use with one (1) to four (4) modules per circuit.
• Maximum power output of 1150W per circuit.
• Peak Efficiency of 96%.
• Comes with a Sun Bandit System Monitor and 30" Wire Whip
SB1200-B AC Micro-Grid Inverter
Te c h n i c a l S p e c i f i c a t i o n s
Number of Inverters / DC Input Channels- 1 / 4
Number of Modules per Channel- 1
Number of Modules per Circuit- 1, 2, 3 or 4
DC Input (per Channel) Data
Recommended PV Module Power Range (STC)- 220 W – 350 W
Operating Input DC Voltage Range- 15 V – 58 V
Peak Power Performance Range- 30 V – 58 V
Maximum Input DC Voltage / Current- 58 V / 9 A
Minimum Starting Voltage- 20 V
AC Output (per Inverter) Data
Maximum Output Power / Rated Output Power- 1150 W / 960 W
Maximum Output Current- 9.5A
Nominal Operating AC Output Voltage- 20 V – 240 V, Single-Phase
Nominal Frequency- 50 Hz – 60 Hz
Load Resistance Range- 12 ohm - 58 ohm
Peak Efficiency / MPPT Tracking- 96% / 99%
Ambient Temperature Range- -40° F to +149° F / -40° C to +65° C
Internal Operating Temperature Range- -40° F to +190° F / -40° C to +88° C
Dimensions w/o mounting bracket (L x H x W)- 12.5” x 9.5” x 2.3” / 32 cm x 24 cm x 5.8 cm
Weight- 14.25 lbs / 6.5 kg
Cooling / Enclosure- Natural Convection, No Fan / Potted
DC / AC Wire, Connectors- 42” CH 1 & 4, 12” CH 2 & 3 DC Wires, MC-4 / 72” AC Wire + 30” Whip (8’-6”)
Features and Compliance Data
Safety and EMC Compliance
UL1741 and IEEE1547 (E113426), CSA 107.1, FCC Part 15 Class A
Compatibility- 60-Cell, 72-Cell and Thin Film PV Solar Panels meeting DC Input above
DC Ground Fault Detector Interrupter (GFDI)- Built-In
Standard Warranty- 6 Years* / 1 Year (* When purchased and installed with a Sun Bandit® Tank and Sun Bandit® Monitor within the United States.)
Enclosure Environmental Rating / Safety Outdoor – NEMA 6 / Transformer Isolated Circuits
Will your tank work with the Sun Bandit SB 1200-B?
The Ohms of your tank's element needs to fall within the range of 12-58 ohm.
Here is how you can check the element:
Voltage squared divided by wattage.
For example: If you have a 3,000W 240VAC element.
240VAC X 240VAC = 57,600
57,600 Divided by 3,000W = 19.2 ohm so this is compatible.
Sun Bandit® Certifications, Specifications and Installation Resources- http://www.sunbandit.us/Resources.aspx
Sun Bandit® System Sizing Performance Calculator- http://sunbandit.us/Choose.aspx
Sun Bandit® FAQ- http://www.sunbandit.us/FAQ.aspx
